Stainless steel pipe 16х1 mm AISI 304 (600 GRIT) — a high-quality round structural metal product of precise gauge, made of premium high-alloy austenitic steel. The product belongs to the category of thin-walled (lightweight) pipes with an outer diameter of 16 mm, a wall thickness of 1.0 mm, and an inner nominal diameter of 14 mm. The production is carried out by welding method using advanced TIG technology with complete technological seam cleaning and multi-stage mirror polishing of the outer weld to a high roughness class of 600 GRIT (chrome, mirror, gloss). The inner surface remains untreated, while the weld itself is visually imperceptible from the outside due to uniform finish processing. The pipe is supplied in bars with a length of 6 meters.
Material of Manufacture and Standards
This profile is manufactured from high-quality chromium-manganese food-grade stainless steel grade AISI 304, which is a well-known analogue of the 08Х18Н10 alloy and the European standard EN 1.4301. Due to its high content of chromium and nickel, this steel grade is distinguished by exceptional anti-corrosion properties, chemical inertness, and increased durability. It does not react with food products, is easily cleaned, and fully complies with strict sanitary and hygienic standards. Production is regulated by international engineering standards ASTM A-554 (USA) and EN 10296-2 (Europe), which guarantees flawless precision of geometric parameters and high reliability of the welded joint.
Scope of Application and Purpose
Due to its perfect mirror shine of the outer surface (600 GRIT), ecological safety of the metal, and lightweight construction of 16х1 mm, the pipe is a versatile material for design and industry. It is actively used for filling handrails and fences, manufacturing lifelines, decorative rungs, handrail tubes, modern furniture frames, balustrades, as well as elements of medical and industrial refrigeration equipment.
Recommended Environment: open air (moderate climate conditions), coastal and beach zones, facilities with high humidity (swimming pools, saunas, bathrooms, restrooms), food blocks and catering establishments (auxiliary structures), medical and laboratory institutions, as well as exhibition halls, stands, and engineering facilities.
Technical and Operational Limitations:
• Structural Purpose: the product belongs to the category of structural thin-walled metal products and is not designed for internal pressure, therefore it is strictly forbidden to use it in hydraulic systems and any pipelines under high pressure.
• Atmospheric Resistance: AISI 304 grade steel possesses excellent resistance to moisture and temperature fluctuations, which allows using it with confidence in places with an unstable or aggressive temperature-humidity regime.
• Temperature Range: the maximum continuous operating temperature is +600°C, the maximum short-term temperature is up to +850°C, and the minimum operation temperature reaches extreme -196°C. Resistance to sharp temperature fluctuations is high.
Technical Recommendations for Mirror Surface Care
Recommended Cleaning Methods:
To preserve the original glossy shine of the 600 GRIT surface, mild soapy solutions or specialized chlorine-free disinfectants should be applied. Cleaning is performed exclusively with a soft cloth or a foam sponge.
Prohibited Care Products:
The use of agents containing chlorine, active acids, as well as abrasive powders and stiff metal brushes is not permitted. Failure to comply with these rules leads to irreversible dulling of the gloss and the appearance of scratches.
The products are delivered in proper commercial condition (new), enclosed in a protective polymer film, which minimizes the risk of accidental damage during logistical operations and installation. The country of origin is China.
The Ukirs company carries out direct supplies and offers to buy stainless steel round food-grade pipes 16х1 mm of AISI 304 grade at the most favorable market cost. Sales are released with a minimum order quantity starting from 3 meters. Fast delivery by verified transport services throughout the territory of Ukraine is provided.
