Stainless steel pipe ∅ 20x1.2 mm 600 GRIT AISI 201 (Product code: 1050)

Views: 12047 | Rating:
• Manufacturer: Vinmay
• Manufacturer code: T201F20-1.2
• UCGFEA: 7306 40 20 90
Grade:

Medium corrosion resistance, non-magnetic - more details...

Wall:

The wall thickness of the product is 1.2 mm.

Cutting:
Shipped in full length6-meter pipe
Prices
102 meter - 204 meter 82 грн. / meter
from 204 meter 81 грн. / meter
Updated:
Available
Quantity in stock: 360
Price: 84 грн. / meter
plus shipping
Qty:
meter

Characteristics Stainless steel pipe ∅ 20x1.2 mm 600 GRIT AISI 201

Actual weight: 0.565 Kg / meter
Dimensions:
Length, L (m): 6
Outer diameter ∅, D (mm): 20
Inner diameter ∅, d (mm): 17.6
Wall thickness, S (mm): 1.2
Manufacturing standards:
Type / by manufacturing method / : welding (TIG - Tungsten Insert Gas)
Standard (USA) / American Society for Testing and Materials / : ASTM A-554
Equivalent (Europe) / European Norm / : EN 10296-2
External surface treatment:
Surface / mirror polished, glossy / : 600 GRIT
Color: chrome
Pattern: mirror
Material of manufacture:
Metal type: stainless steel
Steel grade: AISI 201
Steel Grade Analog: EN 1.4372
Design features:
Construction Type: mechanical (non-pressure)
Operating temperature range
Max. continuous operating temperature: +400°C
Max. intermittent temperature: +550°C
Min. continuous operating temperature: -40°C
Thermal cycling resistance: moderate
Intended Use & Application
Application Areas: bar counters, cafe furniture, sports and gym equipment, showroom display fixtures, heated towel rails, handrail tube
Recommended Environment: office and retail centers, for low humidity interiors, for moderate (non-aggressive) environments, machinery, mechanical engineering
Usage Restrictions: not for high-pressure systems, do not use in environments with constant high humidity
Maintenance recommendations
Recommended cleaning and disinfection products: mild soap solutions, chlorine-free disinfectants, soft cloth or sponge
⛔Prohibited care products and methods: chlorine-based products, active acids, abrasive powders, metal brushes
Additional information:
Order quantity (m): 3
Product condition: new
Packaging: pellicle
Product Type: stainless steel round pipe
Country of Origin: China

Description Stainless steel pipe ∅ 20x1.2 mm 600 GRIT AISI 201

This is a round tube with a cross-section of 20 millimeters in outer diameter and 1.2 millimeters in wall thickness. Its inner diameter is 17.6 mm. 600 GRIT indicates a fairly smooth, polished surface. The material of manufacture is AISI 201 steel (the stainless steel grade from which the tube is made). AISI 201 steel belongs to chromium-nickel-manganese steels, but with a lower nickel content compared to AISI 304. This makes it less resistant to corrosion in aggressive environments. Due to its wall thickness, the tube has sufficient strength for many applications. It provides good corrosion resistance, but less than that of grades with a higher nickel content. The mirror surface gives the tube an attractive appearance. It is well welded using standard methods. It is easily amenable to various types of processing. Due to its properties, the tube will serve for a long time. It is used in various industries, from construction to the food industry. Usually has a more affordable price compared to AISI 304, AISI 321, AISI 316 grades.

Stainless steel pipe ∅ 20x1.2 mm 600 GRIT AISI 201 is a universal material with a good price-quality ratio. It is well suited for many applications where strength, corrosion resistance and an attractive appearance are required. However, when choosing a material for a specific application, it is necessary to take into account its limitations, such as lower corrosion resistance in aggressive environments.
